3/8 Inch NBR Female Hydraulic Brass Quick Coupler

  • 1
  • 2

Brand Name : carterberg

Model Number : CB-5

Certification : IATF16949

Place of Origin : Shanghai, China

MOQ : Negotiation

Price : Negotiation

Payment Terms : L/C, D/A, D/P, T/T, Western Union

Supply Ability : 5000~20000 pc/month

Delivery Time : 7-20 work days

Packaging Details : carton

Thread : Female

Rated Pressure : 34.5 Mpa

Temperature : -20℃to+120℃

Technics : Machinning

Size : 1/4-1

Standard seal material : NBR

Compatible with : GROMELLE 6000 Series and HOLMBURY TGW series

Material : Carbon Steel/ Stainless Steel

Contact Now

Thread locked type hydraulic quick coupling Threaded Quick Connect

3/8 Inch NBR Female Hydraulic Brass Quick Coupler

CB-5 Series couplings with nominal diameters up to and including 25 mm are designed and manufactured under Article 3.3 of the European Pressure Equipment Directive 97/23 EC.

Couplings with nominal diameters greater than 25 mm are designed and manufactured in accordance with the stipulations of Module D1 of the European Pressure Equipment Directive 97/23 EC. They should not be used to convey volatile gases.

Applications

All industrial and severe applications.Public works, offshore, lifting equipment, systems subject to heavy mechanical loads, high pressures

Standard Materials

  • zinc-plated steel, stainless steel
  • Seals: NBR, Viton, EPDM

Features

  1. Double shut-off couplings
  2. Locking by screwing the socket sleeve-nut on to the male-threaded plug. This gives the coupling resistance to heavy mechanical demands (ram loads, hydraulic shocks, severe pulsating pressures, etc.).
  3. Can be connected against residual pressure
  4. Dust caps and plugs
  5. Compatible with GROMELLE 6000 Series and HOLMBURY TGW series.

3/8 Inch NBR Female Hydraulic Brass Quick Coupler

Body Size PARTNO. Thread A B HEX
1/4" CB-S2S-5FN 1/4-18 53 35 19
1/4" CB-S2S-5FG 1/4-19 53 35 19
3/8" CB-S3S-5FN 3/8-18 65 38 23
3/8" CB-S3S-5FG 3/8-19 65 38 23
1/2" CB-S4S-5FN 1/2-14 74 45 27
1/2" CB-S4S-5FG 1/2-14 74 45 27
3/4" CB-S6S-5FN 3/4-14 91 55 35
3/4" CB-S6S-5FG 3/4-14 91 55 35
1" CB-S8S-5FN 1-11 1/2 103 69 41
1" CB-S8S-5FG 1-11 103 69 41

3/8 Inch NBR Female Hydraulic Brass Quick Coupler

Body Size PARTNO. Thread C D HEX
1/4" CB-P2S-5FN 1/4-18 35 15 19
1/4" CB-P2S-5FG 1/4-19 35 15 19
3/8" CB-P3S-5FN 3/8-18 42 19 23
3/8" CB-P3S-5FG 3/8-19 42 19 23
1/2" CB-P4S-5FN 1/2-14 50 22 27
1/2" CB-P4S-5FG 1/2-14 50 22 27
3/4" CB-P6S-5FN 3/4-14 63 29 35
3/4" CB-P6S-5FG 3/4-14 63 29 35
1" CB-P8S-5FN 1-11 1/2 71 36 41
1" CB-P8S-5FG 1-11 71 36 41
